Fowrise 70~110kW Commercial Swimming Pool Heating and Cooling Heat Pump
💎Description:
Commercial pool heat pumps are gradually replacing traditional boilers and electric heating systems, . It works like an air conditioner in reverse—absorbing free heat from the air and transferring it to the pool, energy consumption reduction of over 50% compared to traditional electric heating equipment, leading to significant long-term savings on operating costs.
💎Main Features:
-PVC Titanium heat exchanger with full resistance against corrosion, more durable
– High efficiency compressor,saving energy
– Intelligent controller with WIFI function
– Flow switch for water flow protection
Specification:
| MODEL | FAR02Y | FAR03Y | FAR05Y | FAR06Y | FAR10Y | FAR12Y | FAR15Y | FAR20Y | FAR30Y | |
| Heating Mode | Circulating | |||||||||
| Ambient Temp.Range | ℃ | -10~+43℃ | ||||||||
| Rated Heating Capacity | KW | 9.4 | 13 | 21 | 25 | 38 | 45 | 55 | 85 | 105 |
| Cop | W/W | 5.1 | 5.2 | 5.1 | 5.2 | 5.4 | 5 | 5 | 5.1 | 5.2 |
| Cooling Capacity | Kw | 7.2 | 8.6 | 14.7 | 17.5 | 26.6 | 31.5 | 38.5 | 59.5 | 73.5 |
| EER | W/W | 2.69 | 2.68 | 2.72 | 2.75 | 2.76 | 2.78 | 2.75 | 2.71 | 2.7 |
| Rated Input Power (Heating/Cooling) |
KW | 1.8/2.5 | 2.5/3.2 | 4.24/5.4 | 4.8/6.3 | 7.04/9.6 | 9.3/11.3 | 11.1/14 | 16.7/22 | 20,2/27 |
| Max. Running Current | A | 14 | 8 | 12 | 18 | 20 | 24 | 28 | 35 | 50 |
| Power Supply | / | 220V 1N~50Hz | 380V 3N~50Hz | |||||||
| Ip Code | / | IPX4 | IPX4 | IPX4 | IPX4 | IPX4 | IPX4 | IPX4 | IPX4 | IPX4 |
| Safety Function | / | High and low pressure protection, Overload protection, Temperature protection, Power phase sequence protection, etc. | ||||||||
| Refrigerant Type/Weight | -/kg | R22/R407C/R410A/R417A | ||||||||
| Compressor Qty | PCS | 1 | 1 | 1 | 1 | 2 | 2 | 2 | 2 | 2 |
| Compressor Type | / | Emerson Copeland Scroll | ||||||||
| Max.Temp.Outlet Water | ℃ | 45 | ||||||||
| In/Out Water Connection | DN | DN25 | DN32 | DN40 | DN40 | DN40 | DN50 | DN50 | DN80 | DN80 |
| Water Flow Volume | m³/h | 3.2 | 4 | 6 | 8 | 10 | 12 | 14 | 23 | 28 |
| Air Out Type | / | Horizotal/Vertical | Vertical | |||||||
| Fan Motor Qty | PCS | 1 | 1 | 1 | 1 | 2 | 2 | 2 | 2 | 2 |
| Noise | dB/(A) | 54 | 55 | 58 | 58 | 60 | 65 | 65 | 68 | 68 |
| Condenser | Titanium Tube Heat exchanger | |||||||||
| Evaporator | Inner threaded pipe + hydrophilic aluminum foil | |||||||||
| 4-Way Valve | Sanhua / Saglnomiya | |||||||||
| Electronic Expansion Valve | Sanhua / Saglnomiya / Danfoss | |||||||||
| Contactor | CHNT / Schneider Electric | |||||||||
| Housing Materials | Galvanized/stainless steel | |||||||||
| Controller | LCD controller | |||||||||
| Machine Dimension (L*W*H) | mm | 1010/320/655 | 655/695/810 | 710/710/1010 | 710/710/1010 | 1450//710/1180 | 1540/880/1500 | 1540/880/1500 | 1800/1100/2100 | 1800/1100/2100 |
| Packing Dimension (L*W*H) | mm | 1040/400/695 | 685/725/940 | 740/740/1140 | 740/740/1140 | 1480/740/1310 | 1590/930/1580 | 1590/930/1580 | 1830/1130/2230 | 1830/1130/2230 |
| Net Weight | kg | 85 | 100 | 180 | 200 | 250 | 280 | 310 | 630 | 780 |
| Gross Weight | kg | 88 | 120 | 205 | 230 | 295 | 315 | 350 | 670 | 830 |
| Remarks: | ||||||||||
| 1. Heating working condition: Outdoor DB/WB temp: 24℃/19℃，62.5%RH, inlet water temp：26℃. | ||||||||||
| 2. Cooling working condition: Outdoor DB/WB temp: 43℃/37℃，68%RH, inlet water temp：32℃. | ||||||||||
